Air conditioning unit thermal zone central air conditioner reviews Rooftop air conditioning

Model No.:

VWD-177F

MOQ:

1pcs

Payment:

T/T,L/C

Delivery Time:

30 days after receiving prepayment

Loading Port:

Shenzhen,China

Logo:

VENTECH/VCARE/OEM

samples:

Yes(in charge)

shipping:

sea shipping

Customization:

yes

Air supply:

20100~88600m3/h

Refrigerant:

R22,R407C,R410A

Inquiry

Write a Review

Product Information

Rooftop Package Air Conditioning unit for HVAC system Central Air Conditioner.

Function: Cooling, Electrical heating, Heat Pump, Thermostatic and humidistatic, fresh air, DC inverter.

Refrigerant	R22, R407C, R410A
Cooling Capacity	21.5-575.7 KW
Heating Capacity	22.6-596.4 KW
Condition	New
Air Volume	Up to 90000m³/h

Product Feature

1) Adopt international famous brand hermetic scroll compressores.

2) Unit with Split and monolithic two structures, which are rational layout complete series, easy to use.

3) Unit hace rain-proof and anti-corrosion design: can be directly installed on the roof or outdoor space, with machine room, effectively saving space, saving the initial investment.

4) This series product have cooling, heat pump, thermostatic and hurnkfetatic, purification, flesh air, DC inverter and other functions, suitable in all kind of locations.

5) The unit uese advanced microcomputer control system and advanced thorough security system to ensure the efficient operation of the unit all year around.

Air conditioning unit thermal zone central air conditioner reviews Rooftop air conditioning 2

Product Description

◪ Evaporator and condenser are using with copper aluminium fin.
◪ Temperature controlling range is 16-30℃, temperature controlling accuracy is ± 2℃
◪ Electrical heating is finned type stainless steel electrical heating.
◪ Power consumpting includes the summation of heat pump heating and auxillary electric heating.
◪ Connecting type of cooper is soldering.
◪ The type of power is 380V/3N-50Hz.
◪ Refrigerant: R22.If the refrigerant is R407c.the parameter is ditto.

Parameter	Cooling capacity	Heating capacity	Outdoor body size			Outdoor weight	Indoor body size			Indoor weight	Airflow	ESP	Consumed power (KW)	Noise≤dB(A)
Model	kW	kW	L	W	H	kg	L	W	H	kg	(m³/h)	(Pa)	Cooling
VWD-118F	117.9	117.6	1800	1800	2230	1900	2500	1800	1800	450	20100	250	45.01	77
												450	46.75	77
VWD-126F	125.9	128	1800	1800	2230	1900	2500	2000	1800	500	22800	250	51.04	7S
												450	52.82	78
VWD-134F	134.1	138.5	1800	1800	2230	1900	2500	2200	1800	650	25400	300	55.63	79
												500	57.88	79
VWD-144F	143.9	149.1	1800	1800	2230	1900	2500	2400	1800	700	28100	300	59.67	79
												500	61.94	80
VWD-177F	176.8	176.9	3000	1700	2230	2300	2500	2100	2200	1000	29900	350	69.07	80
												550	71.94	80
VWD-185F	184.9	186.9	3000	1700	2230	2300	2500	2200	2200	1100	31600	350	74.82	80
												550	77.75	81
VWD-193F	199	197.3	3000	1700	2230	2300	2500	2400	2300	1200	37700	350	82.51	81
												550	85.66	81
VWD-201F	201.2	207.8	3000	1700	2230	2300	2500	2600	2300	1360	41300	350	85.66	82
												550	89.33	82
VWD-216F	215.9	223.7	3000	1900	2230	2500	2600	2400	2500	1750	42100	350	89.81	83
												550	93.49	83
VWD-268F	268.3	277	3050	2100	2340	3000	2600	2700	2600	1960	48600	450	118.14	84
												650	122.07	85
VWD-288F	287.9	298.2	3550	2100	2340	3400	2600	2900	2500	2150	51400	500	124.52	85
												700	129.37	85
VWD-350F	350	359.4	3550	2100	2340	3700	2600	2900	2800	2300	57400	500	150.58	86
												700	155.5	86
VWD-402F	402.4	415.5	6000	1700	2230	4200	2600	3200	2800	2460	64000	500	168.57	M
												700	174.93	87
VWD-432F	431.8	447.4	6000	1900	2230	5400	2600	3400	2800	2560	68400	550	180.09	B7
												850	184.84	8S
VWD-528F	527.8	544.6	6000	2300	2230	6000	2600	4000	2900	2750	79300	550	214.36	88
												850	222.37	89
VWD-576F	575,7	596.4	7100	2100	2340	6500	3300	4400	2900	3200	88600	600	245.3	89
												900	253.92	89

ABOUT US

Ventech(Vcare) Whole-house Healthy & Comfortable Air conditioning system, is Committed to provide people with a healthy and comfortable home living environment.

Ventech(Vcare)’s talent technical engineers keep improving the efficiency of the system according to the needs of the market. And Based on a 40,000㎡ modern factory and more than 300 professional workers, Ventech provides high quality Whole-house Healthy & Comfortable Air conditioning system.

How to Get a Quick Quotation of Central AC product?

1. Project Drawing, building layout, equipment BOQ.
2. Project name:building name or building type, such as xxx office project, residential house project etc.
3. Expected shipping date of this project.
4. Project type: tender or self-owned.

Get in touch with us

just leave your email or phone number in the contact form so we can send you a free quote for our wide range of designs
