Ventech 4 way supply air diffuser from China2

Company Advantages
1. Ventech is verified to comply with relevant applicable standards. They are the US, EU, and numerous other standards including ISO, AATC, EDANA, and ASTM. This product is available in various kinds of powder coating
2. Top quality 4 way supply air diffuser is the most important thing Yingde Ventech Air Conditioning Co.,Ltd can do to improve relationships with its customers. This product has been widely used in hotels, buildings, and shopping halls
3. The product has no extra loose thread appearing along the seam. Post sewing, all the threads will be carefully trimmed using clippers or trimmers by workers. It can effectively help circulate air in residential and commercial buildings
4. The product has high stitch quality. It goes through stitches per inch (SPI) check to see the stitch density that may impact the strength, appearance, and performance of a garment seam. It has been certified under CE for safe operation
5. This product is strong and robust. It has a well-made frame that will allow it to maintain its overall shape and integrity. This product has been exported to more than 50 countries





LINEAR SLOT DIFFUSER



VENTECH Linear Slot Diffusers are an attractive alternative to the ceiling or high sidewall supply diffusers. Slot diffusers can be installed individually in set lengths or in a continuous line. They can also be installed in any type of ceiling application.



The modules are available with a 20mm or 25mm Slot with the number of slots ranging from 1 to 6 slots and are further available as fixed or removable core. (Fixed Core - Model LSD-VA, Removable Core – LSD-VB.)



The air pattern control is adjustable from the diffuser face and is achieved by means of an adjustable pattern control with each slot, enabling a full 90º air pattern adjustment. The suggested volume control should be from the main duct run take-off, or from a butterfly damper fitted to the inlet of the cushion head box.

Features:

• ·Concealed screw fixing

  ·Finish: off white standard, other colors on demand

  ·Made from high grade extruded aluminum profiles & sheets.

  ·Accessories: Hit & miss damper, plenum box-top/side entry connection

Details:

• Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010.
• Material thickness: 1.2mm
• Accessory: Adaptor Optional





Drawing- with Adaptor











Company Features
1. All testing reports are available for our 4 way supply air diffuser .
2. Following the service tenet will contribute to the development of Ventech. Inquire online!
